QUICK TS1100 Soldering Station

This soldering station from Quick has a heating element with a maximum power of 90 watts. The station has an LCD display and simple buttons so you can easily set the temperature digitally. The temperature is measured by a sensor in the upper part of the heating core and can be read in real time from the LCD display. In addition, three operating modes can be programmed so that you can quickly switch between different temperature points. These temperature settings can optionally be protected with a password.
The station has an over temperature alarm and a real time ESD ground control function that guarantees electrostatic protection for welding products. Programmable stand-by and automatic shutdown features are also available.

Technical specifications:

Power90 Watts
Temperature200 - 450 °C
Temperature stability± 2 °C
Tip resistance< 2 Ω
Heating methodHigh frequency current
Tip potential< 2 mV
ESD safe
Yes
DisplayLCD
Dimensions137 × 65 × 114 mm
Weight1.4 kg
